Volkswagen1996 Caravelle 2.5 Specs

1996 (T4) Volkswagen Caravelle 2.5 Specs & Performance

1996, 1997 (T4)

 This car has not been completed yet.

Tech Specs Summary


2.5 L Inline 5

100 mph

unavailable

108 hp

20.1 mpg

4 Doors

7 Seats

19.1 ft3
lb
3,748 lbs
Front - FWD

Performance

Performance
Top Speed
100 mph
Power-to-Weight
34.7 lb/hp
Power
108 hp
Torque
140 lb·ft

Gas Mileage

Gas Mileage
Combined
20.1 mpg
Total Range
424 Miles

Gasoline Engine

Gasoline Engine
Capacity
2.5 Liter
150.2 in3
Layout
Inline 5
Aspiration
Natural
Peak Power
108 hp @ 4,500 RPM
110 ps @ 4,500 RPM
Peak Torque
140 lb·ft @ 2,200 RPM
190 N·m @ 2,200 RPM
Valvetrain
SOHC
Valves/Cylinder
2 (10v Total)
Fuel Injection
Multi-point
Position
Front Engine
Orientation
Transversal
Fuel
Gasoline
Fuel Tank Capacity
21.1 Gallons

More Engine Specs

More Engine Specs
Compression Ratio
8.5:1
Bore x Stroke
3.189 x 3.76 in
Bore-Stroke Ratio
0.85:1
Under-Square
Specific Output
0.72 hp/in3
Power/Cylinder
22 hp
Cylinder Volume
30 in3
BMEP
140.7 PSI
9.7 Bar

Drivetrain & Chassis

Drivetrain & Chassis
Driven Wheels
FWD
Front-wheel Drive
Transmission (MT)
5 Speeds
Transmission (AT)
4 Speeds
Tyre Sizes
195/70R15 S
Front Suspension
Double Wishbone
Rear Suspension
Trailing-Arm
Front Brakes
Vented Disc
Rear Brakes
Solid Disc

Dimensions & Practicality

Dimensions & Practicality
Body
Large MPV
Door Count
4
Seat Count
7
Luggage Space
19.1 ft3
Curb Weight
3,748 lbs
Gross Weight
5,842 lbs
Maximum Payload
2,094 lbs
Towing Capacity
4,409 lbs
Length
188.5 in
Width
72.4 in
Height
76.4 in
Wheelbase
115 in
Front Track
62.6 in
Rear Track
61.2 in

Performance Rating-
Environment Rating1
Practicality Rating2.9
